• Heavy-duty insulators, lever, and handle that are all made from fiberglass reinforced thermoset polyester molding compound to withstand the heat and be impact resistant
• Forged one-piece brass alloy body machined to close tolerances on the valve and head seat
• Head assembly machined from copper alloy having four air holes optimizing the air flow to the arc
• Balanced to pivot at the center of the handle for ease of use for all gouging positions, and thereby reduces operator fatigue
• Lever spring rated at 146 lbs. per inch providing excellent clamping pressure on the air carbon-arc electrode
• Pack of 1 EA
• Manufacturer part number: 6106-5006
• UPC Code: Unavailable

Specifications:

• Accepts Flat Carbons [Max] = 5/32 in - 3/8 in
• Accepts Flat Carbons [Min] = 3/8 in
• Accepts Pointed Carbons [Max] = 3/8 in
• Accepts Pointed Carbons [Min] = 3/8 in - 5/32 in; 5/8 in - 3/16 in
• Amps [Max] = 600 A
• Angle [Nom] = 15°
• Applications = Medium-Duty Fabrication; Maintenance; Railroad; Shipyard
• Cable Length [Nom] = 7 ft
• Cable Type = Swivel Cable
• Flow [Nom] = 22 CFM
• Head Type = Round; Flat
• Includes = Torch; Cable Assembly; Hook-Up Kit
• Pressure [Nom] = 80 psi
• Process = Air Carbon Arc Gouging
• Series = K3000
• Type = Medium Duty
• Wt. = 7.2 lb
• This is a normal stocking item.
