Heavy Duty Marine Battery Switch – Rated to 300Amp

Marine grade heavy duty dual battery isolator and change-over switch. Rated 175A continuous at 12V, up to 300A intermittent.

Heavy Duty Marine Grade Battery Isolator and Change-over Switch.

Switch Type: Rotary Switch

Operating Voltage: 6-32 Volts

Continuous Rating: 250 Amps

Electrical life: 10000 times

Number of Positions: 4

Operation: 2-BOTH-1-OFF

Rated for 175A continuous/300A intermittent at up to 32 volts

Isolates 1 battery or 2 batteries, or links up both batteries in parallel

Mounting Type: Surface Mount

Can be used in Dual Battery systems. Capable of switching either or both batteries at the same time.

Integral push lock on knob prevents accidental change over.

Made of Non-Corrosive marine grade metal. This model has a Bakelite base and Bakelite knob.

Colour: Black and Red highlights.

Suitable for surface mounting.

Rated at:

• 175A Continuous duty at 12V
• 300A intermittent

Dimension:

• 133.3mm(Diameter)
• 133.3mm(Height)
